Mercury 6.7L 480 hp Inboard Engine Diesel

Mercury 6.7L 480 hp Inboard Engine Diesel
  • Mercury 6.7L 480 hp Inboard Engine Diesel
Price:
US $19,590.00
Brand:
MERCURY
Condition:
New
Shipping:
Free Shipping
Quantity:

Product Description



Delivers exceptional performance, acceleration and top speed.

Features:

* The Most Powerful Mercury Diesel: The perfect match for recreational sport yachts; Available in pod, inboard and bobtail configurations; 20 percent quicker acceleration and faster top speed than the competition; Compatible with Mercury Zeus pod drives, Mercury Joystick Piloting for Inboards, all Mercury controls and Mercury VesselView displays; Low fuel consumption, for affordable operating costs and extended travel range; Service available through the global Mercury dealer network.
* Clean, Quiet and More Comfortable: Because Zeus drives utilize counterrotating propellers and are mounted on large rubber grommets, gear noise and vibration are significantly reduced for a quiet and comfortable ride. Exhaust fume is nearly eliminated by venting the emission through the propeller hubs where the water flow takes it far back into the wake.
* Zeus Pod Drives - An Unparalleled Level of Control: Zeus pods turn independently, resulting in much greater turning efficiency and responsiveness; Zeus pods create horizontal thrust, driving the boat forward, unlike standard inboard shafts that push the boat upward; The hydrodynamic shape of the Zeus pod creates much less drag than a shaft, strut, and rudder. Additionally, the rear-facing propellers experience less form drag; The counter-rotating propellers in Zeus pods eliminate side forces, minimize cavitation and allow for completely straight tracking.
* Safer by Design: If the Zeus pod drive were to strike underwater debris, the rear-facing propellers are protected by the pod gearcase and skeg. Additionally, Zeus pods are mounted in a tunnel, keeping the torpedo of the pod at the same depth as the keel – offering further protection. Most floating objects will be deflected downward by the keel and skeg, away from the propellers. However, should the unit come into contact with a substantial object, the skeg is designed to shear below the torpedo, minimizing damage to the pod drive and reducing costly repair bills. By offering a rear-facing pod drive mounted in a tunnel, we offer tremendous efficiency improvements without sacrificing safety.
* Zeus Joystick Piloting: With Mercury Joystick Piloting, you have full 360-degree control at your fingertips. With a simple push or twist of the joystick, you can move the boat from side-to-side, diagonally or even spin on a single axis. Maneuvering your boat at low speeds or in close quarters becomes easy, intuitive and stress-free. Joystick Piloting for Zeus is integrated with the pod drives, making it superior to bow thrusters, which can drain your battery and leave you stranded. The system can even be installed on boats with dual helms, for dual, triple or quad pod applications.

Specifications:

* Power mhp / kW: 480 / 353
* Cylinder Configuration: Inline 6
* Dry weight *Lightest model available: 1,590 lb. / 721 kg
* Direction of Rotation: Counter Clockwise
* Valves per Cylinder: 4
* Emission Certification: EPA Tier 3; EU RCD 2; IMO Tier 2
* Bore and stroke: 4.094 x 5.197 in. / 104 x 132 mm
* Air Handling: Turbo Charged and After Cooled
* Rated rpm: 3200
* Max Torque (N-m) at rpm: 1,580 (1,165) @ 1,900
* Engine Cooling: Closed Cooled
* Turbo Cooling: Closed Cooled
* Engine Stop: ECU Controlled
* Flywheel Housing: SAE 3
* Bobtail Length (mm): 1,089
* Bobtail Width (mm): 864
* Bobtail Height (mm): 848
* Inboard: ZF 85IV: 1.64:1, 2.00:1, and 2.49:1
* Inboard: ZF 280IV: 1.25:1, 1.56:1, 1.77:1, 2.06:1, 2.28:1, 2.56:1 and 3.09:1
* Inboard: ZF 280-1: 0.81:1, 1.00:1, 1.06:1, 1.14:1, 1.21:1, 1.30:1, 1.51:1, 1.72:1, 2.00:1, 2.48:1, 3.00:1
* Inboard: ZF 280-1A: 1.12:1, 1.48:1, 1.77:1, 2.00:1, 2.23:1, and 2.48:1
* Displacement (L): 6.7
* Compatible with SmartCraft digital technology: Yes

Engine:

Engine Type : Inline 6
Horsepower : 480 hp (353 kW)
Bore x Stroke : 4.094 x 5.197 in. (104 x 132 mm)
Displacement : 6.7 L

Dimensions:

Length : 1089 mm
Width : 864 mm
Height : 848 mm
Weight : 1,590 lb. (721 kg)

General:

Full Throttle Operating Range : 3200 rpm
Cooling : Closed Cooled
Warranty : 3 Year Corrosion, 3 Year Limited
